| Part Number | ESJMLB31-K10C | Distance | 10km |
| Form Factor | SFP28 | Connector | LC duplex |
| Wavelength | 1310nm | Transmitter | DFB |
| Receiver | PIN | Media | Multi-Mode Fiber(MMF) |
| Power Consumption | <1.2W | Protocol | 25G Base Ethernet |
| Case Temperature(℃) | C: 0℃ to +70℃ / I: -40℃ to +85℃ |
Product Features
Supports 25.78Gbps aggregate bit rate
1310nm DFB laser transmitter and PIN/TIA receiver
Maximum link length of 20km 0n Single Mode Fiber (SMF)
Hot-pluggable SFP28 footprint
Duplex LC receptacles
Single +3.3V ±5% power supply
Maximum power dissipation < 1.2W
Compliant with SFF-8472 & IEEE 802.3cc
Fully RoHS Compliant
Product Highlights
Discover the cutting-edge performance of our 25G SFP28 LR 1310nm 10km transceiver. Engineered for high-speed, long-reach connectivity, this SFP 25GB solution leverages advanced optics to deliver reliable data transmission over 10 kilometers. Ideal for enterprise networks and data centers seeking robust, scalable bandwidth, our 25G SFP28 LR transceiver ensures seamless integration and unparalleled performance. Elevate your network capabilities with the 25G SFP28 Transceiver, designed for the future of high-speed communications.
Autonomous Vehicles and V2X Communication
The 25G SFP28 LR module supports long-distance, high-bandwidth communication between data centers and autonomous vehicle systems in V2X (Vehicle-to-Everything) communication networks. It ensures low-latency data transfer for real-time traffic monitoring, vehicle coordination, and safety systems, enabling intelligent transportation and smart mobility solutions.
Satellite Ground Stations
The 25G SFP28 LR module is used in satellite ground stations to provide long-distance, high-bandwidth communication between satellite systems and ground control stations. It enables fast data transmission for satellite uplinks and downlinks, supporting applications such as weather monitoring, telecommunications, and global navigation.
Rigorous Industrial Product Testing
ESOPTIC is equipped with a comprehensive range of professional testing equipment designed to assess various parameters of optical products.
This ensures the highest performance, quality, and stability of optical transmission in all of our products.
Product packaging specification
Packing of module products
Put the qualified products into the corresponding model blister box packaging.
The bottom, surface and side of the carton are filled with one piece of anti-static foam to protect the product.According to the requirements of the packing quantity, put the blister box box of the product into the packaging carton. If the space between the blister boxes is large, use a piece of anti-static foam to put it in the middle. The empty space in the end box must be filled with anti-static foam to ensure that it will not be damaged during transportation.
The outer case label is attached to the side position of the outer case,Label the outer case after sealing.
At the time of delivery, the entire outer box should be wrapped with at least 2 layers of wrapping film protection.
